Sanitary Plate Heat Exchangers

Sanitary PHES

These applications mandate that PHEs must be all Stainless Steel or Stainless Steel clad to ensure hygiene. The frames of our sanitary plate heat exchangers are either solid stainless steel or clad with 1.5 mm thick SS 304 sheet. The frames are designed for easy cleaning and maintenance. Plates are designed for gentle handling of the food products like milk, ice-cream, beer, wine etc. for superior output quality. Gaskets are always clip-on type.
Our sanitary plate heat exchangers are also available as multi-stage PHEs which are multiple PHEs combined in one, thereby saving cost and valuable space.
Our experience and knowledge of processes in food, dairy, and beverage industries help us to manufacture high efficiency and maintenance friendly plate heat exchangers.

Our service applications:

Cooling, Heating and Pasteurisation of Milk and Milk Products like ice cream
Heating / Cooling of Sugar Syrup and Juices
Cooling and Heating of Vegetable Oil
Wort Cooling and Heating

Product Program

Connections Sizes	DN15 to DN550
Flow Rates	< 6000 m3/hour
Working Pressure	< 25 Bar
Working Temperature	180 deg C (240 deg C for some models)
Plate Materials	SS304 / 316L, SMo254, Titanium Gr 1 / 11, Hastelloy C-276, Ni-201
Gasket Materials	NBR, EPDM, FKM, CR, HNBR, PTFE Encapsulated
Frame Materials	IS2062, SA516 Gr 60/70, SS304, SS304 Cladded
Tie-Rods, Fasteners	IS1367, SA193/SA194, ASTM A193/194
Construction Codes	Standard Engineering Practice, ASME Sec VIII Div 1, PED, U Stamp(*)
Flow Rates	< 6000 m3/hour
Working Pressure	< 25 Bar
Working Temperature	180 deg C (240 deg C for some models)
Plate Materials	SS304 / 316L, SMo254, Titanium Gr 1 / 11, Hastelloy C-276, Ni-201
Gasket Materials	NBR, EPDM, FKM, CR, HNBR, PTFE Encapsulated
Frame Materials	IS2062, SA516 Gr 60/70, SS304, SS304 Cladded
Tie-Rods, Fasteners	IS1367, SA193/SA194, ASTM A193/194
Construction Codes	Standard Engineering Practice, ASME Sec VIII Div 1, PED, U Stamp(*)
